Imex i88G Rotating Laser Kit

Imex i88G Rotating Laser Kit

The most versatile rotating laser level kit on the market. The i88G self-leveling system utilizes leveling sensors with a stepping motor enhancing accuracy. The simplified design and robust component reduces calibration and service requirements. Protected buy a heavy duty, water and dust-proof case, with a fully enclosed laser diode for years of trouble-free use.

With self-leveling, grade slope function, scan mode, horizontal, vertical and plumb spot beams, and remote controller the i88G represents excellent value with many capabilities on the construction site.

SHIPS IN 1 - 2 DAYS
$1,625.00
Order Here
Item Laser Type Unit(s) EX.GST QTY
Item Laser Type Green Rotating Pack Qty.- $ Ex. GST -
BoxVOLUME DISCOUNT:
Close
Qty.
Product List
SKU Item Included Bx. Qty. Crt. Qty.
SKU 13OL012-I088GS Item Imex i88G Rotating Laser Kit Included LRx10 digital reciver, remote, staff & tripod, target plate, USB cable & chargers, 9.0Ah li-ion battery, carry case Bx. Qty. 1 Crt. Qty.

NEW 9Ah Li-ion Battery

The new 3.7v lithium-ion replaces the old ni-mh battery, stepping up the working run time of the i88G before recharging ensuring its always ready to go when you need to. Battery charging can be done whilst the battery remains in the unit while in operation or can also be charged from your vehicle with the supplied car charge plug as standard. Four hour charge time.

Green Beam Technology

The i88G rotating laser level uses a green beam laser diode. The human eye can see the green light beam better than the more common red laser –  these laser diodes use less power for better performance, run cooler, are safer and perform better in both exterior and interior places. Potential eye damage is minimised, and the laser line is more accurate and precise.

Warranty

All backed by Imex warranty, service and innovative approach. The i88G laser includes a Calibration Certificate and a 5 year Warranty, IP66 water resistant/ shockproof casing and the battery in the handle for easy removal whilst the laser is on the tripod.

Kit Includes

  • i88G laser unit with carry case
  • LRx10 digital dector
  • Remote control unit
  • Measuring staff
  • Tripod
  • Target plate
  • Rechargable 9.0Ah li-ion rechargeable battery
  • USB cable and chargers

Specifications

  • Self-levelling Range: +/-5º
  • Accuracy: 1.5mm at 30m
  • Working Distance: dia 600m with included detector
  • Rotation Speeds: 0 / 60 / 120 / 300 / 600 RPM
  • Scan Mode: Yes – 0º / 10º / 45º / 90º / 180º
  • Grade Slope: +/-5º dual grade (X or Y axis) 8.8%
  • Beams: Vertical / Horizontal
  • Plumb Spot: Yes – accuracy +/-1mm at 1.5m
  • Light Source: Green laser diode 535nm
  • Remote Control: Working range approx. 20mm (2x AAA batteries)
  • Water Proof / Shake Proof: IP66
  • Working Temperature: 0º to 40ºC (Storage: -10º to 50ºC)
  • Detector: Double sided operation fine and course setting (9v battery) 45mm range pick up



Ask About This Premium Rotating Laser Level

For a super-accurate and robust Imex rotating laser level, you can't go past this kit. Enquiries? Get in touch with Allfasteners today.
