HDC-FCY Timber Construction Screw Full Thread Cylindrical Head
HDC-FCY Timber Construction Screw Full Thread Cylindrical Head
Construction cylindrical head screws with full thread and TX drive for structural connections and reinforcements of wooden members.
- Solid Timbers
- Glued Laminated Timbers - CLT, KVH, BSH / GLT
- Laminated Veneer Lumber - LVL
Availability:
Require a Quote?
Instant quotes online are available to all our trade customers using Trade Portal.
Login and simply add items into your cart. View and edit your cart before pressing Submit Quote. Quotes will be available instantly online.
Description
FEATURES
- Full Thread - Without elements being over tighten to each other.
- Cylindrical Head - Allow quick and secure fastening , ideal for concealed joints.
- High Torque - Allows screws to be installed without pre-drilling, even in hardwood substrates.
- Wax Coating - Wax coating applied during the production process significantly reduces the torque.
Product List
| SKU | Description | Availability | List Price | Pack |
|---|---|---|---|---|
| Pack: |
More Information
| Coating & Plating | Zinc Clear |
|---|---|
| Material Grade | Carbon Steel |
| Driver Type | Torx Bit |
| Diameter / Gauge | M8, M10 |
| Thread Type | Dual Thread |
| For use with | CLT (Cross Laminted Timber), LVL (Layerd Veneer Lumber), Timber, GLT (Glulam) |
Technical Information
| SKU | Description | Coating | Thread Length | Driver Bit |
|---|---|---|---|---|
| 1213.0060080 | M6 x 80mm HDC-FCY | Zinc White | 72mm | TX30 |
| 1213.0060100 | M6 x 100mm HDC-FCY | Zinc White | 92mm | TX30 |
| 1213.0060120 | M6 x 120mm HDC-FCY | Zinc White | 112mm | TX30 |
| 1213.0060140 | M6 x 140mm HDC-FCY | Zinc White | 132mm | TX30 |
| 1213.0060160 | M6 x 160mm HDC-FCY | Zinc White | 152mm | TX30 |
| 1213.0060180 | M6 x 180mm HDC-FCY | Zinc White | 172mm | TX30 |
| 1213.0060200 | M6 x 200mm HDC-FCY | Zinc White | 192mm | TX30 |
| 1213.0060220 | M6 x 220mm HDC-FCY | Zinc White | 212mm | TX30 |
| 1213.0060240 | M6 x 240mm HDC-FCY | Zinc White | 232mm | TX30 |
| 1213.0060260 | M6 x 260mm HDC-FCY | Zinc White | 252mm | TX30 |
| 1213.0060280 | M6 x 280mm HDC-FCY | Zinc White | 272mm | TX30 |
| 1213.0060300 | M6 x 300mm HDC-FCY | Zinc White | 292mm | TX30 |
| 1213.0080120 | M8 x 120mm HDC-FCY | Zinc White | 108mm | TX40 |
| 1213.0080140 | M8 x 140mm HDC-FCY | Zinc White | 128mm | TX40 |
| 1213.0080160 | M8 x 160mm HDC-FCY | Zinc White | 148mm | TX40 |
| 1213.0080180 | M8 x 180mm HDC-FCY | Zinc White | 168mm | TX40 |
| 1213.0080200 | M8 x 200mm HDC-FCY | Zinc White | 188mm | TX40 |
| 1213.0080220 | M8 x 220mm HDC-FCY | Zinc White | 208mm | TX40 |
| 1213.0080240 | M8 x 240mm HDC-FCY | Zinc White | 228mm | TX40 |
| 1213.0080260 | M8 x 260mm HDC-FCY | Zinc White | 248mm | TX40 |
| 1213.0080280 | M8 x 280mm HDC-FCY | Zinc White | 268mm | TX40 |
| 1213.0080300 | M8 x 300mm HDC-FCY | Zinc White | 288mm | TX40 |
| 1213.0080350 | M8 x 350mm HDC-FCY | Zinc White | 338mm | TX40 |
| 1213.0080400 | M8 x 400mm HDC-FCY | Zinc White | 388mm | TX40 |
| 1213.0080450 | M8 x 450mm HDC-FCY | Zinc White | 438mm | TX40 |
| 1213.0080500 | M8 x 500mm HDC-FCY | Zinc White | 488mm | TX40 |
| 1213.0100300 | M10 x 300mm HDC-FCY | Zinc White | 285mm | TX40 |
| 1213.0100330 | M10 x 330mm HDC-FCY | Zinc White | 315mm | TX40 |
| 1213.0100360 | M10 x 360mm HDC-FCY | Zinc White | 345mm | TX40 |
| 1213.0100400 | M10 x 400mm HDC-FCY | Zinc White | 385mm | TX40 |
| 1213.0100450 | M10 x 450mm HDC-FCY | Zinc White | 435mm | TX40 |
| 1213.0100500 | M10 x 500mm HDC-FCY | Zinc White | 485mm | TX40 |
| 1213.0100550 | M10 x 550mm HDC-FCY | Zinc White | 535mm | TX40 |
| 1213.0100600 | M10 x 600mm HDC-FCY | Zinc White | 585mm | TX40 |
